RCGF Stinger 20cc SE
Latest Design & Strong Power !Starting ease !
Glow size：economy and powerful
NEW ENGINE ,NEW Design,More powerful,Stronger material , More precision , More shining.
NEW RCGF
Stinger 20cc SE is the latest design engine.
It includes a beam mount to make the glow-to-gasoline
upgrade drop-in fast and easy. A rear pumper carb simplifies installation and adjustment.
Parameter
| Type | 2 cycle piston valve type gasoline engine for airplane |
|---|---|
| Displacement (cc) | 20cc (1.22 cu in) |
| Bore x Stroke (mm) | 1.3 in(32mm) x 9.5 in (24mm) |
| Recommended props | 14×10, 15×8, 16×6, 16×8, 17×6 |
| Maximum Output | 2.8HP /2.1KW |
| Power supply | 7.4V-14V |
- Carburetor : Walbro
- Ignition : Stinger DC-CDI (Computer Controlled auto advance, electronic ignition system)
- SPARK PLUG: M8(1/4-32)
- Requires: Gasoline, 2-cycle oil, ignition battery & propeller
- speed rang : 1500-10500rpm
- Gasoline-Version : Pre-mixed Fuel, 25-40 (Gasoline):1 (recommended : 30:1)
- Lubrication Oil : High quality fully synthetic 2 cylinder oil such as Motul 800 2T 100% synthetic racing
motro oil , Red line two-stroke racing motor oil , Stihl Ultra high performance 2 cycle fully synthetic engine oil etc
. - Break in Propeller : 16X8 (Standard Two leafs prop)
- Cooling System : Air Cooled
- RCGF Stinger Engine package Includes: electronic CDI ignition, muffler, spark plug, gaskets, bolts, throttle
arm extension & manual.
Weight:
- Engine: 1.44 lb (614g)
- Muffler: 2.1 oz (59 g)
- Ignition Module: 4.4 oz (125 g)
- Total: Weight: 1.76 lb (798 g)
Technical Data:
- Ignition Battery: 7.4V-14VNiCd or NiMH, 7.4V LiFe or 2S LiPo pack
- Gasoline/Oil Mix: 30:1
- Replacement Spark Plug: M8 1/4-32 or equivalent
- Idle Speed: 1800 rpm/min
