Performance Specifications |
Operating Voltage Range (Volts DC) |
4.8V ~ 6.0V ~ 7.4V |
Speed (Second @ 60°) |
0.28 ~ 0.20 ~ 0.17 |
Maximum Torque Range oz. / in. |
115 ~ 158 ~ 180 |
Maximum Torque Range kg. / cm. |
8.3 ~ 11.3 ~ 12.9 |
Current Draw at Idle |
30 mA |
No Load Operating Current Draw |
500 mA |
Stall Current Draw |
2,650 mA |
Dead Band Width |
2 µs |
Physical Specifications |
Dimensions (Inches) |
1.59 x 0.77 x 1.48 |
Dimensions (Metric) |
40.6 x 19.8 x 37.8 |
Weight (Ounces) |
2.11 |
Weight (Gram) |
57.0 |
Circuit Type |
32bit Programable Digital |
Motor Type |
3 Pole Metal Brush Ferrite |
Gear Material |
Metal |
Bearing Type |
Dual Ball Bearing |
Output Shaft (type / Ømm) |
H25T |
Case Material |
Plastic |
Dust / Water Resistance |
N / A |
Connector Gauge (AWG) / Strand Count |
22 / 60 |
Radio Control Applications |
Parkflyer |
N / A |
Sport Plane |
12 – 15 lbs. |
Sailplane |
2 meters and up |
3D Performance |
12 – 15 lbs. |
Scale |
12 – 15 lbs. |
Electric Helicopter |
600mm |
Gas Helicopter |
50 – 59 Class |
On Road |
1/10th |
Monster Truck |
1/10th |
Buggies |
1/10th |
Truggies |
1/10th |
Short Course / Truck |
1/10th |
Crawlers |
N / A |
Sail Boat |
= >1M & Scale |
Power Boat |
1/10th |
