Performance Specifications |
Operating Voltage Range (Volts DC) |
6.0V ~ 7.4V |
Speed (Second @ 60°) |
0.09 ~ 0.08 |
Maximum Torque Range oz. / in. |
50 ~ 61 |
Maximum Torque Range kg. / cm. |
3.6 ~ 4.4 |
Current Draw at Idle |
12 mA |
No Load Operating Current Draw |
190 mA |
Stall Current Draw |
1,600 mA |
Dead Band Width |
2 µs |
Physical Specifications |
Dimensions (Inches) |
1.28 x 0.66 x 1.29 |
Dimensions (Metric) |
32.4 x 16.8 x 32.8 |
Weight (Ounces) |
1.20 |
Weight (Gram) |
34.0 |
Circuit Type |
G2.5 Programable Digital |
Motor Type |
Coreless Metal Brush |
Gear Material |
Metal |
Bearing Type |
Dual Ball Bearing |
Output Shaft (type / Ømm) |
Standard 24 |
Case Material |
Plastic |
Dust / Water Resistance |
N / A |
Connector Gauge (AWG) / Strand Count |
22 / 60 |
Radio Control Applications |
Parkflyer |
N / A |
Sport Plane |
4 – 12 lbs. |
Sailplane |
2 meters |
3D Performance |
4 – 12 lbs. |
Scale |
4 – 12 lbs. |
Electric Helicopter |
500mm |
Gas Helicopter |
50 – 59 Class |
On Road |
1/12th |
Monster Truck |
N / A |
Buggies |
1/12th |
Truggies |
N / A |
Short Course / Truck |
N / A |
Crawlers |
N / A |
Sail Boat |
<1 meter |
Power Boat |
N / A |
