Performance Specifications |
Operating Voltage Range (Volts DC) |
6.0V ~ 7.4V |
Speed (Second @ 60°) |
0.16 ~ 0.14 |
Maximum Torque Range oz. / in. |
122 ~ 139 |
Maximum Torque Range kg. / cm. |
8.8 ~ 10.0 |
Current Draw at Idle |
7 mA |
No Load Operating Current Draw |
350 mA |
Stall Current Draw |
2,600 mA |
Dead Band Width |
4 µs |
Physical Specifications |
Dimensions (Inches) |
1.59 x 0.77 x 1.48 |
Dimensions (Metric) |
40.6 x 19.8 x 37.8 |
Weight (Ounces) |
2.01 |
Weight (Gram) |
57.0 |
Circuit Type |
G1 Programable Digital |
Motor Type |
3 Pole Metal Brush Ferrite |
Gear Material |
Metal |
Bearing Type |
Dual Ball Bearing |
Output Shaft (type / Ømm) |
Standard 24 |
Case Material |
Plastic |
Dust / Water Resistance |
N / A |
Connector Gauge (AWG) / Strand Count |
22 / 60 |
