Fast, precise and high torque servo for small helicopters, 3D models and hand launched gliders.
Key Features
- Full AVCS Gyro DS mode compliant
- Operating Voltage: 4.8-6.0 Volts
- Operating Speed (4.8V): 0.09sec/60°
- Operating Speed (6.0V): 0.08sec/60°
- Torque (4.8V): 2.0kg.cm
- Torque (6.0V): 2.2kg.cm
- Dead Band Width: ≤3usec
- Dimensions: 23.6 x 11.8 x 22mm
- Weight: 14g
- Bearing Type: Top Ball Bearing
- Gear Type: Metal Gears
- Motor Type: 3-Pole Neodynium Magnet
- Connector Wire Length: 180mm
- Current Drain (4.8V): 5.3mA/idle and 140mA no load operating
- Current Drain (6.0V): 6.6mA/idle and 150mA no load operating
