SEDONA
Item code: BH68
Glow and EP
SPECIFICATION:
– Wingspan: 1,800mm (70.87in).
– Length: 1,470mm (57.87in).
– Weight: 2.6kg (5.72 lbs).
– Wing area: 57.6dm2.
– Wing loading: 45.14g/dm2.
– Servo mount: 42mm x 21mm.
– Wing type: Naca Airfoil.
– Spinner: 58mm.
– Gear type: Aluminium Hi-grade for main gear and spring wire for tail gear (included).
Parts listing required (not included):
– Radio: 04 channels.
– Servo: 04 servos.
– Glow Engine: 61cu.in 2 stroke.
– Motor: Brushless outrunner 1200-2200W, 650KV.
– Propeller: Suit with your engine.
Recommended Motor and Battery set up (not included):
– Motor: RIMFIRE.60.
– Lipo cell: 6 cells 4,000-5,000mAh.
– Receiver battery: 6V/ 1200-2000mAh NiMH.
– ESC: 80A.
ALL BALSA – PLY WOOD CONSTRUCTION.
COVERED IN A HEAT-SHRINK FILM WITH PRINTED.
