PITTS
Item code: BH85
Glow and EP
SPECIFICATION:
– Wingspan : 1,500mm 59.06 in).
– Length : 1,330mm (52.36 in).
– Weight : 4.7kg (10.34 lbs).
– Wing area: 74dm2.
– Wing loading: 64g/dm2.
– Wing type: Naca Airfoil.
– Servo mount: 21mm x 42mm
– Gear type: Aluminium Hi-grade for main gear and spring wire for tail gear (included).
Parts listing required (not included):
– Radio: 06 channels.
– Servo: 07 servos.
– Engine: 120 – 2 stroke; 22cc Gas.
– Motor: Brushless outrunner 1800-2300W, 450KV.
– Propeller: Suit with your engine.
Recommended motor and battery set up (not included):
– Motor: RIMFIRE.120.
– Lipo cell: 6 cells 4,000-5,000mAh.
– ESC: 80A.
– Receiver battery: 6V/ 1200-2000mAh NiMH.
ALL BALSA – PLY WOOD CONSTRUCTION.
COVERED WITH ORACOVER
